Easy MaxFolding Wheelchair

Reduce to the max.

With the Easy max, we have succeeded in designing an adjustable, folding wheelchair which, in terms of handling, is a match for any fixed frame wheelchair. The cross frame ensures excellent handling and means that the folded dimensions are kept small. Minimum weight with maximum functionality were key aspects in the development of the Easy max. Also available as a swing-away model.

Request Brochure

Crash Tested Quickie Easy max Adjustable Wheelchair
Internal cross-brace

Internal cross-brace

The internal cross-brace gives maximum stability and the best drive characteristics - whether the chair is used with swingaway, removable footrests or with two-part foot boards.

Swingaway and removable footrests

Swingaway and removable footrests

The footrests are swingaway and removable. In this way, the Easymax Swingaway now offers even more comfort. This additional functionality opens the door to greater independence.

Aluminium sideguards

Aluminium sideguards

The sideguard line has been extended with aluminium sideguard which has a height-adjustable armrest and now offers more functionality, greater independence and also gives the Easymax Swing a very distinctive look.

Dimensions
Width:SW + 18 cm
Seat Width:34 - 46 cm (in 2 cm increments)
Seat Depth:36 - 50 cm (in 2 cm increments)
Front seat height:46 - 53 cm
Rear seat height:43 - 50 cm
Seat Angle:0° - 12°
Backrest Height:27,5 - 47,5 cm (in 2,5 cm increments)
Backrest Angle:- 9° - + 9° (optional)
Frame Inset:1 cm each side
Camber:0° / 1° / 2° / 3° / 4°
Colours:27 colours
Performance/Weights
Frame Type:105°
Maximum User Weight:120 kg
Total Weight:from 9,8 kg
Transportation
Crash Tested?This product has been successfully crash tested and fulfils the performance requirements for ISO 7176-19

As a part of our ongoing product improvement initiative, Sunrise Medical reserves the right to change specifications and design without notice. Further, not all features and options offered are compatible with all configurations of the wheelchair. Please consult the user instruction manual for more information.

Support

Documentation

Frequently Asked Questions

The total width of your wheelchair can be found in the user manual (or in the ordering documentation of your wheelchair). What is important to know when it comes to manual wheelchairs is if you have a camber, the overall width increases rapidly. For example, a wheelchair with 6 degrees camber and 24 "wheels, becomes 80 mm wider than a chair with 0 degrees camber.

Please consult your user manual for more information on setting changes for your wheelchair.

Yes, our Built-4-Me team can help you achieve requirements that go above and beyond what you would find on the typical product order form. They'll make every effort to provide you with the most suitable solution to your request.

We'd recommend that your wheelchair is serviced by an authorised Sunrise Medical dealership every year. For your safety, some elements of your wheelchair should be checked regularly. Please refer to your user manual for more information.

Ultra-lightweight wheelchairs tend to be made of areospace-grade aluminum or carbon fibre, so they're stronger whilst not compromising the weight of the wheelchair. More durable, ultra-lightweight wheelchairs are custom-built to your needs and are highly customisable with a wealth of features and style options. QUICKIE's range of ultra-lightweight wheelchairs also employ a range of unique patented features to further strengthen the frame whilst minimising weight (such as ShapeLoc Technology on the Xenon series or X-Braid Technology on the Krypton).
