Width:520 (12" Drive Wheels) / 540 (13" Drive Wheels) / 570 mm (14" Drive Wheels)
Length:1060 - 1180 mm (41.5“ - 46.5“)
Seat Width:385 - 510 mm (15" - 20") (2” Extra seat width with SEDEO Pro Single Post Armrests)
Seat Height:410 - 490 mm (16" - 19")
Seat Depth:410 -560 mm (16" - 22")
Seat Tilt: 0° - 12° (Fixed Tilt)
Power Seat Tilt:30° Powered Tilt
Seat Lift:300 mm
Front seat height:410 mm - 490 mm
Additional Growth (Width):2"
Backrest Height:460 -510 mm (18" - 20")
Back Recline:-4°, 0°, 4°, 8° & 12°
Turning Radius:560 mm (22")
Centre of Gravity:Yes
Castor Wheel:7"
Drive Wheel:12" / 13" / 14"
Max. Range:36 km
Speed:6 kph / 8 kph / 10 kph
Batteries:41 Ah / 56 Ah
Maximum Safe Slope:6°
Max Kerb Climb:70 mm (12” Drive Wheels) / 70 mm (14” Drive Wheels)
Light And Indicators:Yes
Electronics:VR2 / R-Net
Min. Weight:from 103 kg (inc. 41 Ah batteries)
Total Weight:103kg (41Ah Batteries)
Maximum User Weight:136 kg
Crash Tested?This product has been successfully crash tested and fulfils the performance requirements for ISO 7176-19
